Sailor Special
Reverse Osmosis Watermaker
Sailor Special Compact series has been designed with the scope to reduce the energy demand per produced liter of freshwater.
Thanks to an overall process improvement and to the installation of highly innovative membranes, the system allows energy savings of 35% compared to other conventional desalination equipments.
All series is equipped with an advanced microprocessor control box for a fully automatic system that can be switched to manual operation, if needed.
The Tecnicomar Sailor Special Compact stands out for simplicity of use and high quality components like the stainless steel high pressure pump with solid ceramic plungers, the powder coated stainless steel frame, FDA compliant filters and ASME & TÜV certified pressure vessels.
The Sailor compact series is also available in aluminum version, solution that allows to save weight keeping at the same time the structural quality of the frame.
The standard configuration includes a full-featured, ready to install watermaker with automatic pressure regulation and installation kit. On request, the system can be supplied with automatic membrane flushing, remote control and a wide range of post filtration optional.
Sailor Special Compact series has been designed with the scope to reduce the energy demand per produced liter of freshwater.
Thanks to an overall process improvement and to the installation of highly innovative membranes, the system allows energy savings of 35% compared to other conventional desalination equipments.
All series is equipped with an advanced microprocessor control box for a fully automatic system that can be switched to manual operation, if needed.
The Tecnicomar Sailor Special Compact stands out for simplicity of use and high quality components like the stainless steel high pressure pump with solid ceramic plungers, the powder coated stainless steel frame, FDA compliant filters and ASME & TÜV certified pressure vessels.
The Sailor compact series is also available in aluminum version, solution that allows to save weight keeping at the same time the structural quality of the frame.
The standard configuration includes a full-featured, ready to install watermaker with automatic pressure regulation and installation kit. On request, the system can be supplied with automatic membrane flushing, remote control and a wide range of post filtration optional.
Remote control by PC
7″ LCD touch-screen display remote control
Automatic membranes flushing filter
Re-hardening filter TCC-SL 10
Carbon filter TCA-SL 10
Maintenance kit
CDMAR-2 Remote Control
| Model | Production per hour (litres / gallons) |
Production per day (litres / gallons) |
Voltage (volt) / Frequency (hz) Installed Power (kW) |
Max Dimensions -L x W x H- (mm) |
Weight (kg) |
|---|---|---|---|---|---|
| Sailor Special 2/21 | 100/28 | 2400 / 634 | 4000 VAC - 50 Hz 3-phase - 2.2 kW | 750 x 520 x 360 | 52 |
| Sailor Special 3/21 | 160/42 | 3840 / 1024 | 4000 VAC - 50 Hz 3-phase - 2.2 kW | 750 x 520 x 360 | 55 |
| Sailor Special 2/40 | 250/66 | 6000 / 1585 | 4000 VAC - 50 Hz 3-phase - 4 kW | 1170 x 520 x 360 | 64 |
| Sailor Special 3/40 | 350/92 | 8400 / 2219 | 4000 VAC - 50 Hz 3-phase - 4 kW | 1170 x 520 x 360 | 68 |
| Sailor Special 2/44 | 600/158 | 14400 / 3794 | 4000 VAC - 50 Hz 3-phase - 5.5 kW | 1270 x 600 x 440 | 95 |
| Sailor Special 3/44 | 800/210 | 19200 / 5059 | 4000 VAC - 50 Hz 3-phase - 5.5 kW | 1270 x 600 x 600 | 110 |
Remote control by PC
Carbon filter TCA-SL 10
Re-hardening filter TCC-SL 10
CDMAR-2 Remote Control
7″ LCD touch-screen display remote control
Automatic membranes flushing filter
Maintenance kit
| Model | Production per hour (litres / gallons) |
Production per day (litres / gallons) |
Voltage (volt) / Frequency (hz) Installed Power (kW) |
Max Dimensions -L x W x H- (mm) |
Weight (kg) |
|---|---|---|---|---|---|
| Sailor Special 2/21 | 100/28 | 2400 / 634 | 4000 VAC - 50 Hz 3-phase - 2.2 kW | 750 x 520 x 360 | 52 |
| Sailor Special 3/21 | 160/42 | 3840 / 1024 | 4000 VAC - 50 Hz 3-phase - 2.2 kW | 750 x 520 x 360 | 55 |
| Sailor Special 2/40 | 250/66 | 6000 / 1585 | 4000 VAC - 50 Hz 3-phase - 4 kW | 1170 x 520 x 360 | 64 |
| Sailor Special 3/40 | 350/92 | 8400 / 2219 | 4000 VAC - 50 Hz 3-phase - 4 kW | 1170 x 520 x 360 | 68 |
| Sailor Special 2/44 | 600/158 | 14400 / 3794 | 4000 VAC - 50 Hz 3-phase - 5.5 kW | 1270 x 600 x 440 | 95 |
| Sailor Special 3/44 | 800/210 | 19200 / 5059 | 4000 VAC - 50 Hz 3-phase - 5.5 kW | 1270 x 600 x 600 | 110 |
